XJet

Groundbreaking powderless 3D nanoprinting systems for precise, fully finished stainless steel and ceramic parts with no post-processing

Certifications:

Locations:

Israel

Mountains in Clouds
White Waves

Why XJet?

XJet's innovative nanoparticle jetting technology revolutionizes additive manufacturing to achieve intricate, fully finished stainless steel and ceramic parts. This novel process eliminates the need for powder and post-processing, streamlining the creation of highly precise and complex components.

Capabilities

A groundbreaking leap in additive metal has emerged, capable of jetting nanoparticles of stainless steel and ceramic into complex, material-dense shapes without powder or post-processing. XJet's fully automated nanoprinting streamlines manufacturing by eliminating the time-consuming and costly cleanup that is required by legacy metal printing.


XJet's innovative technology allows for the direct fabrication of complex geometries and fine details with exceptional precision. These capabilities unlock new possibilities for industries such as aerospace, medical, and electronics. By enabling rapid and efficient production of high-performance parts with enhanced functionality, XJet has the potential to transform manufacturing and accelerate the development of advanced technologies.


XJet's nanoparticle jetting (NPJ) technology was developed over several years and involves more than 80 patents granted and pending. NPJ has been refined with a clear vision to deliver a digital, direct material printing process to additive metal and ceramics. In contrast to loose powder, at the core of XJet’s solution is a dispersion ink which eliminates many of the constraints and drawbacks of powder-based metal printing.


XJet has the additive industry’s only support material that can be rinsed away hands-free in a fully automated support removal process. XJet's patented nanoprinting systems are safe and sustainable: no hazardous powders or lasers, and recirculated inkjet material for minimal waste.

XJet’s 3D Nanoprinting systems:


Carmel 1400M Metal System | Carmel 1400C Ceramic System


  • Build area: 19.7 x 5.5 in / 500 x 140 mm

  • Build tray: 108 in² (700 cm²) - one of the industry’s largest

  • Layer thickness: 7-10 microns

  • Building speed: Up to 0.7 mm height per hour

  • Dimensions (w/h/d): 122 x 84 x 73 in / 310 x 212 x 185 cm

  • Part Accuracy: ±50 micron on dimensions up to 5mm

  • Minimum part feature size: 200 microns


Carmel 5000X Metal & Ceramic System


  • Build area: 19.7 x 11 in / 500 x 280 mm

  • Build tray: 217 in² (1,400 cm²) - one of the industry’s largest

  • Layer thickness: 7-10 microns

  • Building speed:  ï¼ž1.0 mm height per hour

  • Dimensions (w/h/d): 122 x 84 x 73 in / 310 x 212 x 185 cm

  • Part Accuracy: ±50 micron on dimensions up to 5mm

  • Minimum part feature size: 200 microns


Contact us for more information and sample parts.

Natural Cosmetics Oil

XJet’s materials are the result of years of development.


XJet's Stainless Steel materials have high strength, heat and corrosion resistance, and superior performance at high temperatures:

  • Stainless Steel 17-4 PH - 97% density

  • Stainless Steel 316L - 98% density


XJet's ceramic materials are high-strength, insulated, wear-resistant, and have heat and corrosion resistance:

  • Ceramic: Zirconia (ZR02) - 99.5% density

  • Ceramic: Alumina - Aluminum Oxide (AI203) - 99.5% density
